Large Power Outboard Engine

Brief Introduction

Name of products: Large Power Outboard Engine

Products Series: Clutch Hydraulic Landing Series

Model: 7GJ200-80

Material: Cast Steel、Cast Iron or Stainless Steel, etc.

Specification: 1.0-3.0Meters

Supporting Engine Power: 100-160P

Advantage:

1. Engage Gear no noise、Diesel Engine and outboard engine are directly connected,high transmission efficiency.

2. Adapt to work over a long distance and for a long time.

Precision-Engineered Propulsion: HAIYAN Outboard Motors for Small Boats

The HAIYAN brand outboard motors from Bainen Company are meticulously designed to offer high precision and reliability for small boat propulsion. Each motor features a combination of a top and bottom gear reduction box, a tubular body assembly, and a high-performance propeller, all working in harmony to deliver optimal power transmission. This setup ensures that the boat moves efficiently, both forward and backward, under varying water conditions.

Positioned at the stern of the boat, power is transmitted via a triangular belt system, which, when coupled with the dual-stage bevel gears in the upper and lower gearboxes, optimizes the engine speed for smooth propeller rotation. This intelligent design enables the motor to perform consistently, whether navigating calm waters or tackling more turbulent conditions.

Available in both the clutch-fixed line and hydraulic outboard series, the HAIYAN motors cater to a wide variety of users. The clutch-fixed line is ideal for those who prefer manual control, while the hydraulic series provides advanced steering capabilities for those requiring precision navigation. Both options are built for durability and efficiency, making them reliable choices for long-term use, even in harsh marine environments.
